TF-Pro 300 DC ControlPro water-cooled

TIG welding Welding range 3~ 400 V: [A] 5 - 300 Voltage range: [V] 10.2 - 20 TIG Duty cycle AC 400 V Duty cycle AC 100% (40°c): [A] 200 Duty cycle AC 60% (40°c): [A] 230 Duty cycle AC at max. current (40°c): [%] 30 TIG Duty cycle DC 400 V Duty cycle DC 100% (40°c): [A] 230 Duty cycle DC 60% (40°c): [A] 270 Duty cycle DC at max. current (40°c): [%] 45 Electrode welding Welding range 400 V: [A] 10 - 200 Voltage range: [V] 20.4 - 28 Weldable electrodes: [Ø in mm] 1.5 - 5 Electrode duty cycle Duty cycle 100% (40°c): [A] 170 Duty cycle 60%: [A] 200 Duty cycle at max. current (40°c): [%] 60 Process-independent data Open circuit voltage: [V] 77 - 87 Mains 400 V Mains voltage 3~ (50/60 Hz): [V] 400 Mains fuse 3~ (50/60 Hz): [A] 16 Positive mains tolerance 3~ (50/60 Hz): [%] 15 Negative mains tolerance 3~ (50/60 Hz): [%] 15 Mains plug Mains plug: CEE 16 Standards and approvals Protection class: IP23S Insulation class: F Norm/Standard: EN 60974-01 Designation/Certification: CE, S Cooling type Cooling type: Gas-cooled , Water-cooled Cooling Standard cooling capacity (l/min): [kW] 1.14 Tank capacity: [l] 3.4 Dimensions length x width x height Dimensions (LxWxH) [mm] 880 × 400 × 755 Weights Weight: [kg] 67
